DSP5200.2 Active Loudspeaker – Pair (Black).

Sale!
DSP5200.2 Active Loudspeaker – Pair (Black)

The DSP5200.2 is a floorstanding digital active loudspeaker supplied here as a matched stereo pair in piano lacquer black. Each loudspeaker contains a complete, self-contained audio system with Meridian’s latest DSP code, three 75W power amplifiers (225W total) and a three-way driver array using dual 160mm polypropylene long‑throw bass drivers and a 25mm aluminium‑composite dome tweeter with silver voice‑coil. Meridian’s DSP technology and on‑board amplification replace traditional passive crossovers and external power amplifiers, creating authentic, natural and lifelike sound in small to medium rooms of around 20–30m². With in‑room frequency response within 3dB from 35Hz to over 20kHz, peak output of 116dB at 1 metre and overall distortion typically below 0.02% at any frequency or level, the DSP5200.2 delivers truly full‑range performance from a compact footprint cabinet.

SKU MA-DSP5200.2-BLK. Categories , Brand:
Original price was: $18,999.00.Current price is: $6,999.00.

Key Features

  • Digital active loudspeaker with integrated amplification — each DSP5200.2 houses DSP crossovers, DACs and dedicated power amplification inside the cabinet, removing the need for separate power amps and passive loudspeaker networks.
  • Three‑way, three‑amplifier design with 225W total power — every loudspeaker employs three 75W power amplifiers (225W total per cabinet) to drive two 160mm polypropylene long‑throw bass drivers and a 25mm aluminium‑composite dome tweeter, with Meridian Bespoke Signal Mapping providing precise control over each driver’s output.
  • Full‑range performance with 116dB peak SPL — delivers peak output of 116dB at 1 metre with noise below 15dB SPL, and in‑room frequency response within 3dB from 35Hz to over 20kHz, for powerful, detailed and natural sound from a modest‑height enclosure.
  • Enhanced Bass Alignment (EBA) and E3 Bass — Enhanced Bass Alignment uses digital filters and timing to align low frequencies with mid and high frequencies, while E3 Bass processing extends and enhances low‑frequency response so bass performance far exceeds expectations for the cabinet size.
  • Full Frequency Alignment (FFA) — FFA applies digital filters and delay to correct group delay across the audible band, ensuring all frequencies reach the listener at the same time and improving timing, imaging and overall coherence.
  • Advanced Meridian DSP technologies — Q‑Sync minimises jitter through FIFO buffering for improved timing and clarity, True Time apodising filters reduce pre‑ringing and clean up artefacts from earlier filters, and True Link provides secure, high‑integrity transmission of high‑definition digital audio over SPDIF connections.
  • Pro‑Active Bass and Pro‑Active Thermal protection — Pro‑Active Bass monitors low‑frequency energy to protect the bass drivers from over‑excursion, while Pro‑Active Thermal supervises mid and high‑frequency drivers and gently limits overall level if there is any risk of the drive units overheating during extended listening.
  • Free‑Q room compensation — Free‑Q adjustment compensates for acoustic effects of loudspeaker placement in the room, helping maintain a balanced response whether the DSP5200.2 is positioned closer to walls or further into the listening space.
  • SpeakerLink and digital inputs/outputs — Meridian SpeakerLink (RJ45) and RCA phono digital inputs accept 24‑bit audio with sampling rates from 32kHz to 96kHz, and matching SpeakerLink and RCA digital outputs pass high‑resolution audio and control data on to additional Meridian loudspeakers or system components.
  • Refined piano black cabinet with custom finishes — the low‑resonance, multi‑layer, cold‑grown birch plywood cabinet stands 903mm tall and tapers from 300mm at the base to 178mm at the front, finished as standard in piano lacquer black with a wide range of bespoke colour finishes available to suit local interiors.
